| Ask Lasest Price | |
| Brand Name : | YES |
| Model Number : | YES-1 |
| Certification : | CE ISO RHS |
| Payment Terms : | T/T, L/C, Western Union, MoneyGram |
| Supply Ability : | 300 sets per month |
| Delivery Time : | 1 days after payment received |
Double Side PCB Depaneling Tool 4.0mm Thick With Electronic Eye Safe Sensor
Good Quality PCB Separator MAESTRO 4M YES-1 Updating Safety
operate:
This pcb depaneling can connect with production line,automatic delivery the pcb the separate and then automatic transport separated pcb through conveyor belt to the assembly line.
The PCB is placed with its pre-scored groove onto the linear blade,when the foot swith is pressed,the blade carrier with the circular blade moves across the PCB,separating it into individual units.
Safe operation equipped with Electric eye safe sensor to keep your workers safety
No Stress on PCB type PCB Depaneling Tool YES-1 important Function:
1. The feed distance of the knife wheel is from 0 to 500mm(the tool
length can be customized ) . The height of the knife wheel is
fine-tuning from 0 to 2mm,so that it is suitable for PCB of various
kinds of thickness and the depth of V-CUT groove. The height of
work station is regulable from 0 to 50mm.
2. The machine can be in supporting use of a complete set of
conveyor belt,which is convenient for the cut PCB to be send out
automatically.
3. The platform is adjustable. It is good for the product quality when lifting the platform, because it will reduce stress and will not hurt the product.
4. The spacing device applies to products of different size, so as
to improve the work efficiency.
Motorized PCB Depaneling machine Overview:
| Model | YES-1 |
| Max. PCB singulation length | 460 or 600 mm(on request custom made) |
| PCB singulation thickness | 0.6-3.5 mm |
| PCB singulation feed rate | 100,200,300,500 mm/sec |
| Blade motion | upper circular blade moving automatically |
| Power supply | 110/220v |
| PCB singulation machine size | 770*510*450mm |
YES1 PCB Depaneler advantage
1. Engineers available to service machinery oversea
Engineers are available to be sent to freign countries to do machinery training and offer technical support.
2. Effective customer service
All of us together are stronger and wiser than any one of us individually. To succeed, we must assume responsibility, cooperate with fellow associates and with departments, effectively comminicate with one another, foster enthusiam and participate in decision-making. To be seay reachable by customers and provide prompt replies to solve their problems and create value for customers.
3. One year warranty for the machines except accessories
Robust frame construction and Japanese steel blades obtained good appraise and recognized by and oversea clients.
We offer parts for replacement under warranty free of charge, clients only need to bear freight charge.
Motorized PCB Cutter Stress-free separation of pre-scored PCBs
This motorized pcb depaneler separates both large and small PCBs quickly, economically and without stress. Cutting with only a single traverse of the pre-scored groove causes tensile and compressive stresses that can damage sensitive components near the groove. Even a second traverse of the groove accompanied by an adjustment of the blade distance substantially reduces the tensile and compressive stresses. This significantly improves the quality of the populated PCBs.
|
|
